Rigol MSO2000A Series Programming Guide

RIGOL 2 Command System
2-224 MSO2000A/DS2000A Programming Guide
[:SOURce<n>]:FREQuency[:FIXed]
Syntax
[:SOURce<n>]:FREQuency[:FIXed] {<frequency>|MINimum|MAXimum}
[:SOURce<n>]:FREQuency[:FIXed]? [MINimum|MAXimum]
Description
Set or query the output frequency of the specified signal source channel when the modulation of the
specified signal source is not enabled; set or query the carrier frequency of the specified signal source
channel when the modulation of the specified signal source is enabled. The default unit is Hz.
Parameter
Name Type Range Default
<frequency> Real
Sine: 100mHz to 25MHz
Square: 100mHz to 15MHz
Pulse: 100mHz to 1MHz
Ramp: 100mHz to 100kHz
Built-in waveform: 100mHz to 1MHz
Arbitrary waveform: 100mHz to 10MHz
1kHz
<n> Discrete {1|2} 1
Explanation
This command is not available when the waveform currently selected is DC or noise.
Return Format
The query returns the frequency of the waveform currently selected in scientific notation.
[:SOURce<n>]:PHASe[:ADJust]
Syntax
[:SOURce<n>]:PHASe[:ADJust] {<phase>|MINimum|MAXimum}
[:SOURce<n>]:PHASe[:ADJust]? [MINimum|MAXimum]
Description
Set or query the start phase of the waveform currently selected. The default unit is °.
Parameter
Name Type Range Default
<phase> Real 0° to 360° 0°
<n> Discrete {1|2} 1
Return Format
The query returns the current start phase in scientific notation.
