:FUNCtion:WANalyze:TDISp
Syntax
:FUNCtion:WANalyze:TDISp <bool>
:FUNCtion:WANalyze:TDISp?
Description
Enable or disable the template display; or query the current status of template display.
Parameter
Name Type Range Default
<bool> Bool {{0|OFF}|{1|ON}} 0|OFF
Return Format
The query returns 0 or 1.
:FUNCtion:WANalyze:SETup:SSTart
:FUNCtion:WANalyze:SETup:SSENd
Syntax
:FUNCtion:WANalyze:SETup:SSTart <start>
:FUNCtion:WANalyze:SETup:SSTart?
:FUNCtion:WANalyze:SETup:SSENd <end>
:FUNCtion:WANalyze:SETup:SSENd?
Description
Set or query the screen start point or end point of waveform analysis.
Parameter
Name Type Range Default
<start> Integer 5 to 685 5
<end> Integer 15 to 695 695
Explanation
 The screen start point set should be less than the “screen end-10”.
 The screen end point set should be greater than the “screen start+10”.
Return Format
The query returns an integer.
