RIGOL 2 Command System
2-296 MSO2000A/DS2000A Programming Guide
:TRIGger:RS232:LEVel
Syntax
:TRIGger:RS232:LEVel <level>
:TRIGger:RS232:LEVel?
Description
Set or query the trigger level in RS232 trigger. The unit is the same with the current amplitude unit.
Parameter
Name Type Range Default
<level> Real
When the trigger source is CHANnel1 or CHANnel2:
-5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet
When the trigger source is any of D0-D15: -20V to 20V
0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Return Format
The query returns the trigger level in scientific notation.
:TRIGger:RS232:PARity
Syntax
:TRIGger:RS232:PARity <parity>
:TRIGger:RS232:PARity?
Description
Set or query the even-odd check mode in RS232 trigger when the trigger condition is Error or Check Error.
Parameter
Name Type Range Default
<parity> Discrete {EVEN|ODD|NONE} NONE
Note: The even-odd check mode can not be set to NONE when the trigger condition is Check Error.
Explanation
To set the trigger condition, refer to the
:TRIGger:RS232:WHEN command.
Return Format
The query returns EVEN, ODD or NONE.
