Rigol MSO2000A Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-319
:TRIGger:USB:MLEVel
:TRIGger:USB:PLEVel
Syntax
:TRIGger:USB:MLEVel <level>
:TRIGger:USB:MLEVel?
:TRIGger:USB:PLEVel <level>
:TRIGger:USB:PLEVel?
Description
Set or query the trigger level of the D- or D+ data line in USB trigger. The unit is the same with the current
amplitude unit.
Parameter
Name Type Range Default
<level> Real
When the D- data line or D+ data line is CHANnel1 or CHANnel2:
-5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet
When the D- data line or D+ data line is any of D0-D15: -20V to 20V
0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Return Format
The query returns the trigger level in scientific notation.
:TRIGger:USB:SPEed
Syntax
:TRIGger:USB:SPEed <value>
:TRIGger:USB:SPEed?
Description
Set or query the signal speed in USB trigger
Parameter
Name Type Range Default
<value> Discrete {LOW|FULL} LOW
Return Format
The query returns LOW or FULL.
