Rigol MSO2000A Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-21
:BUS<n>:PARallel:BSET
Syntax
:BUS<n>:PARallel:BSET <b0>[,<b1>[,<b2>…[,<b17>]]]
:BUS<n>:PARallel:BSET?
Description
Set the data width of the specified bus in parallel decoding and the channel source for each bit; or query
the channel source of each bit.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<b0> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
D0
…… …… …… ……
<b15> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
D15
<b16> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel1
<b17> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel2
Explanation
This command sets the bus data width and the setting sequence of the bits is LSB. For example, when the
parameter is set to CHAN2,CHAN1, the bus data width is set to 2, bit 0 is CHAN2 and bit 1 is CHAN1.
Return Format
The query returns the channel source of each bit in the current data channel. The number of the channel
sources is determined by the current data width and multiple channels are separated by commas.
Example
:BUS1:PARallel:BSET CHANnel1,CHANnel2,D0,D1
/*Set the data width to 4 and the channel sources of the bits are
CH1,CH2,D0,D1 respectively*/
:BUS1:PARallel:BSET? /*The query returns CHAN1,CHAN2,D0,D1*/
