Rigol MSO2000A Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-23
:BUS<n>:PARallel:OFFSet
Syntax
:BUS<n>:PARallel:OFFSet <val>
:BUS<n>:PARallel:OFFSet?
Description
Set or query the vertical offset in parallel decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<val> Integer
Normal
[1]
: -166 to 148
Statistic
[2]
: -163 to 143
Half screen
[3]
: -103 to 52
0
Note
[1]
: The screen display is normal and the statistic function is not enabled (refer to
the
:MEASure:STATistic:DISPlay command).
Note
[2]
: The screen display is normal and the statistic function is enabled (refer to the :MEASure:STATistic:DISPlay
command).
Note
[3]
: The screen is divided into two windows (refer to the :TIMebase:DELay:ENABle and :CALCulate:FFT:SPLit
commands).
Explanation
 Before using this command, enable the bus display (refer to the
:BUS<n>:DISPlay command).
 When the data line locates at the middle of the screen, <val> is 0; when it locates at the upper side
of the screen, <val> is positive; when it locates at the lower side of the screen, <val> is negative.
Return Format
The query returns the offset in integer.
