Rigol MSO2000A Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-33
:BUS<n>:IIC:SCLK:THReshold
Syntax
:BUS<n>:IIC:SCLK:THReshold <thre>
:BUS<n>:IIC:SCLK:THReshold?
Description
Set or query the clock channel threshold of IIC decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<thre> Real -5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet 0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Explanation
This command is only available when the clock channel source is CH1 or CH2.
Return Format
The query returns the threshold in scientific notation.
:BUS<n>:IIC:SDA:SOURce
Syntax
:BUS<n>:IIC:SDA:SOURce <sour>
:BUS<n>:IIC:SDA:SOURce?
Description
Set or query the data channel source of IIC decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<sour> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel2
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1 or
CHAN2.
