:CURSor:MANual:CAX
:CURSor:MANual:CBX
Syntax
:CURSor:MANual:CAX <ax>
:CURSor:MANual:CAX?
:CURSor:MANual:CBX <bx>
:CURSor:MANual:CBX?
Description
Set or query the horizontal position of cursor A or cursor B in manual cursor measurement.
Parameter
Name Type Range Default
<ax> Integer 0 to 699 150
<bx> Integer 0 to 699 550
Explanation
The horizontal and vertical positions of the cursor are defined by the pixel coordinate of the screen. The
pixel coordinate of the screen ranges from (0,0) to (700,400). Wherein, (0,0) is located at the left top
corner of the screen and (700,400) is located at the right bottom corner of the screen. The horizontal
pixel range is from 0 to 699 and the vertical pixel range is from 0 to 399.
Return Format
The query returns an integer between 0 and 699.
