Rinstrum R427 User Manual

Reference Manual Rev 1.13
Page 78 004R-646-113
NONE
(Default)
SINGLE
DOUBLE
FLASH
SINGLE: single BEEP
DOUBLE: double BEEP
FLASH: flash display
SOURCE: Select which weight values the setpoint
checks against the target weight. Options are:
GROSS: Gross weight always
NET: Net weight always
GR.or.NT: Gross or Net depending on which
one is displayed.
ALT.GR: Alternate Gross weight always
ALT.NET: Alternate Net weight always
ALT.G.or.N: Alternate Gross or Net
depending on which one is displayed
IO: Use the external IO
STATUS: Use the instrument status
SETP: Use the setpoint status
REG: Uses a register value
HYS: Hysteresis defines the amount of weight
required for an active setpoint to become inactive
again.
A value of 0 still allows for 0.5 graduations of
hysteresis.
MASK: a 32 bit number that is used by the logic
setpoints to match IO1..IO32
DELAY: If the timing has been set to PULSE this
sets the delay before each pulse.
ON: If the timing has been set to PULSE this sets
the duration of each pulse.
RDY.TIM: The time that the scale must be in the
zero band and stable before the SC.REDY setpoint
will become active
TIMING(K404 and K405 only): Select the timing
which is applied to the setpoint output. Options are:
LEVEL: Setpoint follows the weight.
EDGE: Setpoint is edge triggered.
PULSE: Setpoint output is pulsed.
LATCH: Setpoint output is latched.
RESET(K404 and K405 only): Select which IO is
used as an input to disable the setpoint. Options are
NONE, IO1..IO32
PLS.NUM: If the timing has been set to PULSE this
sets the number of pulses to be output each time
the setpoint is triggered.
RST.LGC: This setting determines whether the
input used to reset the setpoint is active when the
value is LOW or HIGH.
SOURCE Values <OPT>
 GROSS
(Default)
 NET
 GR.or.NT
 ALT.GR
 ALT.NET
 ALT.G.or.N
(*)
NB: Only for OVER,
UNDER and ZERO setpoints.
 IO
(Default)
 STATUS
 SETP
 REG
(***)
NB: Only for LGC.AND,
LGC.OR and LGC.XOR
setpoints.
HYS Values <NUM>
0 to 999999
Default: 0
(**)
NB: Only for OVER, and
UNDER setpoints.
MASK Values <NUM>
0 to 16777215 Default 0
(***)
NB: Only for LGC.AND,
LGC.OR and LGC.XOR
setpoints.
DELAY Values <NUM>
0.040 to 60.000s Default:
0.040s
(****)
NB: Only for PULSE
TIMING setpoint.
ON Values <NUM>
0.040 to 60.000s Default:
0.040s
(****)
NB: Only for PULSE
TIMING setpoint.
RDY.TIM Values <NUM>
0.000 to 60.000 s
Default: 0.000s
(****)
NB: Only for SC.REDY
setpoints.
TIMING Values <OPT>
LEVEL
(Default)
, EDGE,
PULSE, LATCH
RESET Values <OPT>
NONE
(Default)
, IO1..32
