I/O Expander: Output Parameters
Activates the utility output when the selected zones are disarmed.
Defines the User Code(s) for triggering the selected utility output (UO). The
activation of the UOUO is performed from the User Activities menu. Use the
key to toggle between [Y] YES or [N] NO for each user chosen to trip the
designated Utility Output.
For each output you need to define the pattern of operation. The available
options are:
Pulse N/O (Normally Open)
The utility output is always Deactivated (N/O) before it is triggered (pulled
up).
When triggered, it activates (pulled down) for the Pulse Duration specified, then
deactivates automatically.
Latched N/O (Normally Open)
The utility output Utility Output is always Deactivated (N/O) before it is
triggered (pulled up). When triggered, it activates (pulled down) and remains
activated (latched) until the operation is restored.
Pulse N/C (Normally Closed)
The utility output is always Activated (N/C) before it is triggered (pulled down
to negative). When triggered, it deactivates for the Pulse Duration specified
below and then reactivates automatically.
Latched N/C (Normally Closed)
The utility output Utility Output is always Activated (N/C) before it is
triggered (pulled down to negative). When triggered, it deactivates and
remains deactivated (latched) until the operation is restored.
