Rockwell Automation Publication 2711R-UM001I-EN-E - February 2023 107
Chapter 6 Troubleshoot the System
Communication 27 Remote Device /*S:0 Param1*/ is Not Responding
Verify that all network connections are correct.
Verify that the communication network cable is connected.
If new ladder logic is downloading to the controller, you could see
this message. After the download, communication should run
normally.
Verify that the network address of the controller matches the
terminal controller address that is configured in the
Communication tab.
In the Communication tab, verify that the protocol specifications
are correct, such as communication rate, data bits, stop bits.
These are all protocol specific.
Communication 28 Invalid Data Address /*S:0 Param1*/ This is not syntactically a valid address.
Communication 30
Bad address in block /*S:0 Param1*/ to /*S:0 Param2*/ on
device /*S:0 Param3*/
This can occur when a write-only address for a controller has
been set for read/write in the external tag of the terminal. Param1
to Param2 specifies the address block having the issue.
Somewhere within the range is where the write-only address is
defined in a PanelView external tag. Set the external tag to write.
Recipe 1001 Recipe upload started.
This message is for informational purposes. No corrective action
needed.
Recipe 1002
Recipe save failed. Cause: Recipe in Table has not been
modified.
Make sure that the recipe table is modified before the save
operation is done.
Recipe 1003 Recipe save had errors.
This message is for informational purposes. No corrective action
needed.
Recipe 1004 Recipe save completed successfully.
This message is for informational purposes. No corrective action
needed.
Recipe 1005 Recipe download failed. Cause: Operation canceled.
This message is for informational purposes. No corrective action
needed.
Recipe 1006 Recipe download started.
This message is for informational purposes. No corrective action
needed.
Recipe 1007 Recipe download completed with errors.
This message is for informational purposes. No corrective action
needed.
Recipe 1008 Recipe download completed successfully.
This message is for informational purposes. No corrective action
needed.
Recipe 1009
Recipe Download failed. Cause: Unable to write to /*S:0
Param1*/.
Check for:
Communication errors.
Bad data point specification.
The ingredient value that is written is outside the Low EU and
High EU limits of the numeric data point assigned. (These are
optional OPC defined properties representing data point
minimum and maximum values). The ingredient value could not
be converted to the type of the data point assigned.
Recipe 1010 Recipe upload completed with errors.
This message is for informational purposes. No corrective action
needed.
Recipe 1011 Recipe upload completed successfully.
This message is for informational purposes. No corrective action
needed.
Recipe 1012 Recipe restore failed. Cause: Operation canceled.
This message is for informational purposes. No corrective action
needed.
Recipe 1013
The status data point for Recipe /*S:0 Param1*/ operation
could not be written to. Data Point= /*S:0 Param2*/
Check for:
Communication errors
Bad status data point specification
The status value that is written is outside the Low EU and High EU
limits of the numeric data point assigned. (These are optional
OPC defined properties representing data point minimum and
maximum values). The status value could not be converted to the
type of the data point assigned
Recipe 1014
Recipe download failed. Cause: The value /*S:0 Param1*/ is
less than the minimum value /*S:0 Param2*/ allowed for
ingredient /*S:0 Param3*/
Correct the dataset value.
Recipe 1015 Recipe /*S:0 Param1*/ failed. Cause: No Selector on display. Add a recipe selector device to the screen.
Recipe 1016
Recipe /*S:0 Param1*/ failed. Cause: No DataSet Selector on
display.
Add a dataset selector device to the screen.
Recipe 1017 Recipe /*S:0 Param1*/ failed. Cause: No Table on display. Add a Recipe Table Panel device to the Screen.
Recipe 1018
Recipe /*S:0 Param1*/ operation was not started because the
system is currently busy performing another Recipe operation.
Wait for a recipe operation to complete before starting the next
recipe operation.
PanelView 800 Terminal Alerts (Continued)
Category ID Description Corrective Action
