Preface
About This Publication
This manual provides information for configuring the PanelView™ 800
terminal. You can configure the terminal, through a web browser
(a)
on a
computer connected to the terminal, or through Connected Components
Workbench™ software. This manual also provides information on how to
troubleshoot the PanelView 800 terminal.
Download Firmware, AOP,
EDS, and Other Files
Download firmware, associated files (such as AOP, EDS, and DTM), and access
product release notes from the Product Compatibility and Download Center at
rok.auto/pcdc
.
Summary of Changes
This publication contains the following new or updated information. This list
includes substantive updates only and is not intended to reflect all changes.
Who Should Use this Manual
Use this manual if you are responsible for configuring, operating, or
troubleshooting the PanelView 800 terminals.
No special knowledge is required to understand this manual or operate the
terminal.
Equipment installers must be familiar with standard panel installation
techniques.
(a) The web browser feature is not supported on PanelView 800 terminals from firmware
revision 3.011 onwards.
Topic Page
Removed appendix Specifications this manual
Added support for CompactLogix 5380 controllers throughout
Added statement on firmware support of VNC feature throughout
Updated list of supported operating systems for Connected Components Workbench software 46
Updated screen captures of Connected Components Workbench software in Figure 2 52
Added section Supported Communication Protocols to Chapter 3 75…85
Updated topic Firmware Installation Using Removable Storage Device 123
Added section Extract RFU Files from the DMK File 124
Updated sections Transfer Firmware to the Storage Device and Install Firmware From the
Storage Device
124
Updated topic CompactLogix 5370 and CompactLogix 5380 Controller Cable Charts 133
Updated Appendix D to include support for CompactLogix 5380 controllers 137
