154 Rockwell Automation Publication 2711R-UM001I-EN-E - February 2023
Appendix E PanelView Explorer
2. Repeat step 1 as the target moves around the screen.
3. Tap OK when the message appears to accept the changes.
If you do not tap the screen within 30 seconds, the calibration data is
discarded and the current settings are retained.
Restart the Terminal
You can restart the terminal without having to disconnect and reapply power.
After a reset, the terminal performs a series of startup tests and then either
enters configuration mode or runs the startup application.
Follow these steps to restart the terminal from PanelView Explorer.
1. Go to the PanelView Explorer Startup window.
2. Click the Terminal Settings link.
3. Click the Display/Input tab.
To Next Page
