56 Rockwell Automation Publication 2711R-UM001I-EN-E - February 2023
Chapter 3 DesignStation in Connected Components Workbench Software
Add Ingredients to a Recipe A recipe can hold up to 50 ingredients. Each ingredient is created as a separate
row in the recipe table. When you create a recipe, a row is automatically added
for the first ingredient. Each recipe must have at least one ingredient.
Follow these steps to add ingredients to a recipe.
1. Select a recipe in the Recipe List.
2. Click the Add Ingredient button for each ingredient you want to add to
the recipe.
3. For each ingredient:
a. Change the name of the ingredient if necessary.
b. Select the tag to store the value of the ingredient.
c. Select a numeric or string data type for the ingredient.
d. Enter a minimum and maximum value for the ingredient if the data
type is numeric.
e. Enter a value for each ingredient.
Delete Ingredients from a Recipe
Follow these steps to delete ingredients from a Recipe.
1. Click the space on the left of the ingredient to select the entire row.
2. Click Delete Ingredient.
3. Click Yes to confirm.
Download Recipes Recipes are downloaded together with the application into the PanelView 800
terminal. See Downloading Applications
on page 53 for information on how to
download applications to the terminal.
