132 Rockwell Automation Publication 2711R-UM001I-EN-E - February 2023
Appendix C Cable Connections and Communication
Connecting Devices Use these cables for connecting devices to PanelView 800 terminals.
MicroLogix Controller Cable
Charts
The chart provides a summary of terminal connections to controllers and
network interface modules.
Micro800 Controller Cable
Charts
The chart provides a summary of terminal connections to controllers and
network interface modules.
Cables for PanelView 800 Terminals
Cat. No. Description
2711P-CBL-EX04 Ethernet crossover CAT5 cable 4.3 m (14 ft)
1747-CP3 Serial 9-pin D-shell to 9-pin D-shell null modem cable
1761-CBL-PM02 Serial 9-pin D-shell to 8-pin mini DIN cable, 2 m (6.56 ft)
2711C-CBL-AB03 RS-485 5-pin to RJ45 cable
1763-NC01 Series A 8-pin Mini DIN to 6-pin RS-485 terminal block
PanelView 800 Terminal Connections to MicroLogix Controllers
Protocol PanelView 800 Port
MicroLogix
(8-pin Mini DIN) 1000,
1100, 1400, 1200LSP,
1500LSP (Ch 0)
MicroLogix
(9-pin D-shell) 1500LRP
(Ch 1)
MicroLogix
1100/1400 RS-485 (1763-
NC01)
MicroLogix
1100/1400 Ethernet
DF1 RS-232 1761-CBL-PM02 1747-CP3 — —
DH-485
RS-232 1761-CBL-PM02 1747-CP3
Use AIC+ module (1761-
NET-AIC) connect to port 3
—
RS-485
(1)
——
Belden 3106 A or #9842 or
equivalent
—
Modbus RS-232 1761-CBL-PM02 1747-CP3
Use AIC+ module (1761-
NET-AIC) connect to port 3
—
Ethernet (MicroLogix/ENI)Ethernet———CAT 5 Ethernet
(1) RS-485 is isolated. We recommend that you connect only one device. Multi-node communication is supported when appropriate hardware, such as 1747-AIC or AIC+ is added to the wiring.
PanelView 800 Terminal Connections to Micro800 Controllers
Protocol PanelView 800 Port Micro820® Micro830® Micro850®/Micro870®
Modbus
RS-232
–
(1)
1761-CBL-PM02 1761-CBL-PM02
RS-485
(2)
–
(2)
–
(2)
–
(2)
Ethernet 2711P-CBL-EX04 (CAT5 Ethernet) — 2711P-CBL-EX04 (CAT5 Ethernet)
Ethernet (AB CIP) Ethernet 2711P-CBL-EX04 (CAT5 Ethernet) — 2711P-CBL-EX04 (CAT5 Ethernet)
Serial (AB CIP) RS-232
–
(2)
1761-CBL-PM02 1761-CBL-PM02
(1) Terminal block, wiring required.
(2) RS-485 is isolated. We recommend that you connect only one device.
