Rockwell Automation Publication 2711R-UM001I-EN-E - February 2023 67
Chapter 3 DesignStation in Connected Components Workbench Software
Alarm List Filter The Alarm List object displays the list of alarms that occurs on the terminal.
You can filter the list to display all alarms that have occurred, or only the active
alarms.
Follow these steps to add an Alarm List object to your PanelView 800
application.
1. In Connected Components Workbench software, double-click an
application screen to open it.
2. Drag-and-drop an Alarm List object
from the Toolbox onto the screen.
3. Right-click the Alarm List object and
select Properties.
Configure the properties as
required.
• Display Active Alarm: By default, all
alarms are displayed. When the
value of the tag is “1”, only the active
alarms are displayed.
Import Tags From a
Controller
You can import tags from a CompactLogix controller or Micro800 controller
into your PanelView 800 application.
IMPORTANT If the data type of a controller tag is not supported by PanelView 800,
the tag is not shown in the Tag Selector dialog. However, if the tag
contains sub tags that have supported data types, then the main tag
and sub tags are shown in the Tag Selector dialog.
