24 Rockwell Automation Publication 2711R-UM001I-EN-E - February 2023
Chapter 2 Configure the Terminal
Edit a Recipe
Follow these steps to rename or delete a recipe.
1. Go to the File Manager screen.
2. Select the application that you want to edit the recipe, then press Recipe.
3. Press Edit Recipe.
The name of the currently loaded application is displayed, and a list of
the recipes for that application.
4. Select the recipe from the recipe list.
5. Press Delete if you wish to delete the recipe, then press OK to confirm.
6. Press the blue area next to Name to change the name of the recipe.
IMPORTANT Renaming of a recipe in a design secured application is not
allowed.
IMPORTANT Deletion of a recipe in a design secured application is not
allowed.
Recipe
Back
Copy Recipe Edit Recipe
Edit Recipe
Back
Delete
Application Name:
Name:
Recipe1
Recipe2
Recipe1
Recipe3
Recipe5
PV800_App1
To Next Page
Loading...
