Rockwell Automation Publication 2711R-UM001I-EN-E - February 2023 37
Chapter 2 Configure the Terminal
2. Press Display.
3. Press Screen Saver.
4. Use the up and down arrow keys to select the screen saver, then press Set
to use it or Delete to remove it from the terminal.
5. Select the Mode.
Mode = Disable, Image, Dimmer, Image and Dimmer.
6. Select the brightness.
Brightness 0…100, increments of 1.
7. Select the idle timeout.
Choices are 1, 2, 5, 10, 15, 20, 30, or 60 min.
“RA_DEFAULT” is the default terminal screen saver and cannot be deleted.
You cannot delete the current screen saver. The terminal prompts and
error if you try to do so.
Display
Back
Brightness
Orientation (Requires Reset)
Calibrate Touchscreen
Screen Saver
Font
100
0 degrees
Screen Saver
Back
Mode
Current Screen Saver: RA_DEFAULT
Brightness
Timeout
11
10 Min
Delete
Set
RA_DEFAULT
Screen Saver 1.bmp
Screen Saver 2.bmp
