Rockwell Automation PowerFlex 700

5-2 Programming and Parameters
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
UTILITY
Diagnostic
229 [Alarm 1 @ Fault]
Captures and displays [Drive Alarm 1] at the time of the last fault.
Read Only
Alarms
259 [Alarm Config 1]
Enables/disables alarm conditions that will initiate an active drive alarm.
File Group
No. Parameter Name & Description Values
Bit
Definition
Ground Warn Load Loss In PhaseLoss Motor Therm Waking Decel Inhibt Drv OL Lvl 2 Drv OL Lvl 1 IntDBRes OH Anlg in Loss Str At PwrUp Power Loss UnderVoltage Prechrg Actv
Default x00000000x000000
Bit 1514131211109876543210
1 = Condition True
0 = Condition False
x = Reserved
Bit
Definition
Active Cnvtr PTC HW Prof SetHome Adj Volt Ref
Default xxxxxxxxxxx0x000
Bit 31302928272625242322212019181716
1 = Condition True
0 = Condition False
x = Reserved
Bit
Definition
Ground Warn Load Loss In PhaseLoss Motor Therm Waking Decel Inhibt Drv OL Lvl 2 Drv OL Lvl 1 IntDBRes OH Anlg in Loss Str At PwrUp Power Loss UnderVoltage Prechrg Actv
Default x00000000x000000
Bit 1514131211109876543210
1 = Condition True
0 = Condition False
x = Reserved
Bit
Definition
Active Cnvtr PTC HW Prof SetHome Adj Volt Ref
Default xxxxxxxxxxx0x000
Bit 31302928272625242322212019181716
1 = Condition True
0 = Condition False
x = Reserved
