Supplemental Drive Information A-5
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Horsepower/Current
Ratings
The following tables provide normal duty and heavy duty drive ratings
(including continuous, 1 minute, and 3 second).
Table A.A 400V AC Ratings (AC Input/AC Output)
Table A.B 480V AC Ratings (AC Input/AC Output)
Table A.C 600V AC Ratings (AC Input/AC Output)
Table A.D 690V AC Ratings (AC Input/AC Output)
Drive
Catalog
Number
Frame
PWM
Freq.
(kHz)
Output Power Output Current (with 400V AC Induction Motor)
(1)
(1)
Frame 2 ratings are based on 50°C ambient and 50°C coolant.
Frame 3A and 3B ratings are based on 40°C ambient and 40°C coolant.
HP (kW)
Cont. 110%
1 min.
150%
3 secs.
Cont. 150%
1 min.
200%
3 secs.
ND HD ND ND ND HD HD HD
20LC360 2 4 268 (200) 200 (150) 360 396 540 264 396 540
20LC650 3A 4 500 (370) 365 (270) 650 715 975 475 715 975
20LC1K2 3B 4 960 (715) 700 (525) 1250 1375 1875 915 1375 1875
Drive
Catalog
Number
Frame
PWM
Freq.
(kHz)
Output Power Output Current (with 480V AC Induction Motor)
(1)
(1)
Frame 2 ratings are based on 50°C ambient and 50°C coolant.
Frame 3A and 3B ratings are based on 40°C ambient and 40°C coolant.
HP (kW)
Cont. 110%
1 min.
150%
3 secs.
Cont. 150%
1 min.
200%
3 secs.
ND HD ND ND ND HD HD HD
20LD360 2 4 300 (224) 235 (175) 360 396 540 264 396 540
20LD650 3A 4 600 (445) 440 (325) 650 715 975 475 715 975
20LD1K2 3B 4 1150 (860) 845 (630) 1250 1375 1875 915 1375 1875
Drive
Catalog
Number
Frame
PWM
Freq.
(kHz)
Output Power Output Current (with 600V AC Induction Motor)
(1)
(1)
Frame 3A and 3B ratings are based on 40°C ambient and 40°C coolant.
HP (kW)
Cont. 110%
1 min.
150%
3 secs.
Cont. 150%
1 min.
200%
3 secs.
ND HD ND ND ND HD HD HD
20LE425 3A 4 465 (345) 345 (255) 425 470 640 315 470 640
20LE800 3B 4 870 (650) 640 (480) 800 885 1200 590 885 1200
20LE1K1 3B 2
(2)
(2)
Must operate at 2 kHZ PWM only, and only as a stand-alone inverter module (“K” in catalog string position 13).
1275 (955) 935 (695) 1175 1295 1765 860 1295 1765
Drive
Catalog
Number
Frame
PWM
Freq.
(kHz)
Output Power Output Current (with 690V AC Induction Motor)
(1)
(1)
Frame 3A and 3B ratings are based on 40°C ambient and 40°C coolant.
HP (kW)
Cont. 110%
1 min.
150%
3 secs.
Cont. 150%
1 min.
200%
3 secs.
ND HD ND ND ND HD HD HD
20LF380 3A 4 475 (355) 350 (260) 380 420 570 280 420 570
20LF705 3B 4 881 (657) 650 (485) 705 780 1060 520 780 1060
20LF1K0 3B 2
(2)
(2)
Must operate at 2 kHZ PWM only, and only as a stand-alone inverter module (“K” in catalog string position 13).
1315 (980) 965 (720) 1050 1155 1575 770 1155 1575
