Frame 3A and 3B Installation 3-7
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Figure 3.6 Frame 3B Power Module Installation Dimensions
Recommended Mounting Clearances for Power Modules
Specified vertical clearance requirements (Figure 3.7) are intended to be
from power module to cabinet surface. Other objects can occupy this space;
however, reduced air flow may cause protection circuits to fault the module.
In addition, inlet air temperature must not exceed the product specification.
44 (1.75)
44 (1.75)
23 (0.90)
21 (0.81)
21 (0.81)
76 (3.00)
44 (1.75)
44 (1.75)
16 (0.62)
16 (0.62)
25 (1.00)
37 (1.44)
29 (1.12)
57 (2.25)
DETAIL A
BACK VIEW LEFT SIDE VIEW FRONT VIEW
DETAIL B DETAIL C
51 (2.00)
97 (3.82)
55 (2.16)
57 (2.24)
57 (2.24)
51 (1.99)
37 (1.46)
104 (4.08)
89 (3.51)
75 (2.95)
24 (0.94)
567 (22.32)
51 (1.99)
AIRFLOW
1326 (52.20)
275 (10.83)
255 (10.05)
461 (18.16)
231 (9.09)
231 (9.09)
265 (10.44)
402 (15.81)
368 (14.50)
1200 (47.25)
12 (0.45)
39 (1.56)
175 (6.89)
15 (0.60)
39 (1.56)
175 (6.89)
See
DETAIL B
See
DETAIL A
DC Neg.
DC Pos.
Ø
14 (
Ø
0.56)
Ø
14 (
Ø
0.56)
Ø
14 (
Ø
0.56)
See DETAIL C
GRD
R/L1
or
U/T1
S/L2
or
V/T2
T/L3
or
W/T3
Dimensions are in millimeters and (inches).
Approximate Weight kg (lbs.)
Power Module Power Module and Packaging
132 (290) 166 (365)
