Overview P-7
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Complete Drive Data
Nameplate Locations
Frame 2
Figure P.2 shows multiple data nameplate locations for the drive. The data
and agency markings are different for equipment type. For example, the
complete drive is UL listed component; and the Power Modules are UL
recognized.
Figure P.1 Frame 2 Drive Data Nameplate Locations
SIDE VIEW
Complete Regenerative Drive
Output: 3 Phase, 0-400Hz
Made in the U.S.A. (FAC1C)
Nom. Coolant Pressure
20LC360N3ENNAN10WA
Input: 3 Phase, 47-63 Hz
MFD. in 2007 on JUL 05
Normal Duty Power
AC Voltage Range
Amps
Base Hz (default)
Continuous Amps
Rated Coolant
AC Voltage Range
Nominal Voltage
NEMA Type
Cat No.
Serial Number: MEAE2WJ0
Frame: 2
Original Firmware V. x.xxx
Series: A
Complete Regenerative Drive
Output: 3 Phase, 0-400Hz
Made in the U.S.A. (FAC1C)
Nom. Coolant Pressure
20LC360N3ENNAN10WA
Input: 3 Phase, 47-63 Hz
MFD. in 2007 on JUL 05
Normal Duty Power
AC Voltage Range
Amps
Base Hz (default)
Continuous Amps
Rated Coolant
AC Voltage Range
Nominal Voltage
NEMA Type
Cat No.
Serial Number: MEAE2WJ0
Frame: 2
Original Firmware V. x.xxx
Series: A
FRONT VIEW (Cover Removed)
