Frame 2 Installation 2-21
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Figure 2.18 Frame 2 700S Phase II Control Synchronization Cable Connection
Inverter-to-Converter DPI Communication Cable
To enable the Inverter and Converter section of the Frame 2 drive to
communicate with each other, a factory-installed DPI communications
cable is used. No user connection is required.
P6 Header on
700S Phase II
Control Cassette
Control Synchronization
Cable (Factory-Installed)
J9 Header on
Active Converter
Control Cassette
