A-4 Supplemental Drive Information
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Derating Guidelines
Altitude
Above 1000 m (3280 ft.), derate the output current by 1% for every 100
additional meters (328 additional feet). This is applicable to filters and
power modules. PowerFlex 700L 600/690V drives should not be used above
2000 m (6562 ft.) due to voltage spacing requirements.
Ambient
Frame 2 drives have a maximum ambient of 50C (122F). Frame 3A and 3B
drives have a maximum ambient of 40C (104F). PowerFlex 700L drives
cannot be derated to operate at higher temperatures.
Carrier Frequency
For Frame 2 drives, refer to the carrier frequency derating table below.
PowerFlex 700L Frame 3A and 3B drives cannot be run above 4 kHz.
Feedback
(700S Phase II
Control only)
Encoder Input:
Encoder Voltage Supply:
Maximum Input Freq:
Dual Channel Plus Marker, Isolated with differential transmitter Output (Line Drive) Incremental,
Dual Channel Quadrature type
5V DC or 12V DC (5V DC requires an external power supply), 320 mA/channel
400 kHz
Stegmann Hi-Resolution Option
Encoder Voltage Supply:
Hi-Resolution Feedback:
Maximum Cable Length:
RS-485 Interface:
Customer-I/O Plug (P1) - Hi
Res:
11.5V DC @ 130 mA
Sine/Cosine 1V P-P Offset 2.5
182 m (600 ft.)
Hi-Resolution Feedback Option card obtains the following information via the Hiperface RS-485
interface shortly after power-up: Address, Command Number, Mode, Number of Turns, Number
of Sine/Cos cycles, and Checksum.
Allen-Bradley PN: S94262912
Weidmuller PN: BL3.50/90/12BK
Resolver Option
Excitation Frequency:
Excitation Voltage:
Operating Freq. Range:
Resolver Fdbk. Voltage:
Maximum Cable Length:
2400 Hz
4.25-26V rms
1-10 kHz
2V ± 300 mV
304.8 m (1000 ft.)
DriveLogix
(700S Phase II
Control only)
User Available Memory Base: 1.5 megabytes
Battery: 1756-BA1 (Allen-Bradley P/N 94194801) 0.59g lithium
Serial Cable: 1761-CBLPM02 to 1761-NET-AIC
1761-CBLPA00 to 1761-NET-AIC
1756-CP3 directly to controller
1747-CP3 directly to controller
Category 3 (2)
Compact I/O Connection: Up to (30) modules
Cable: 20D-DL2-CL3 or 20D-DL2-CR3
Category
Specification
Frame 2 Frames 3A and 3B
2
0
4
6
8
360
Output
(Amps)
293 Amps
(80%)
Carrier Frequency (kHz)
