Overview P-3
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
The following publications provide specific feedback card information for
PowerFlex 700L drives with Optional 700S Phase II Control:
The following publication provides information that is necessary when
applying the 700S Phase II Control DriveLogix™5730 Controller:
The following publications provide information that is useful when
planning and installing communication networks:
Manual Conventions
• In this manual we also refer to the PowerFlex 700L Liquid-Cooled AC
Drive as drive, PowerFlex 700L or PowerFlex Drive.
• To help differentiate parameter names and LCD display text from other
text, the following conventions are used:
– Parameter Names appear in [brackets] – example: [DC Bus Voltage].
– Display Text appears in “quotes” – example: “Enabled.”
• The following words are used throughout the manual to describe an
action:
Title Publication
Hi-Resolution (Stegmann) Feedback Option Card Installation Instructions for PowerFlex 700S Drives 20D-IN001
Resolver Feedback Option Card Installation Instructions for PowerFlex 700S Drives 20D-IN002
Multi-Device Interface Option Card Installation Instructions for PowerFlex 700S Drives 20D-IN004
Title Publication
DriveLogix™5730 Controller User Manual 20D-UM003
Title Publication
ControlNet Coax Tap Installation Instructions 1786-5.7
ControlNet Cable System Planning and Installation Manual 1786-6.2.1
ControlNet Fiber Media Planning and Installation Guide CNET-IN001
SynchLink™ Design Guide 1756-TD008
Word Meaning
Can Possible, able to do something
Cannot Not possible, not able to do something
May Permitted, allowed
Must Unavoidable, you must do this
Shall Required and necessary
Should Recommended
Should Not Not recommended
