Overview P-5
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Catalog Number Explanation
a
Drive
Code Type
20L PowerFlex 700L
b
Voltage Rating
Code Voltage Ph.
C400V AC3
D480V AC3
E600V AC3
F690V AC3
c1
ND Rating
400V, 60 Hz Input
Code Amps Hp (KW) Frame
360 360 268 (200) 2
650 650 500 (370) 3A
1K2 1250 960 (715) 3B
c2
ND Rating
480V, 60 Hz Input
Code Amps Hp (KW) Frame
360 360 300 (224) 2
650 650 600 (445) 3A
1K2 1250 1150 (860) 3B
c3
ND Rating
600V, 60 Hz Input
Code Amps Hp (KW) Frame
425 425 465 (345) 3A
800 800 870 (650) 3B
1K1 1175 1275 (950) 3B ♣
♣ Must operate at 2 kHZ PWM only, and only as a
stand-alone inverter module (“K” in position 13).
c4
ND Rating
690V, 60 Hz Input
Code Amps Hp (KW) Frame
380 380 475 (355) 3A
705 705 881 (657) 3B
1K0 1050 1310 (980) 3B ♣
♣ Must operate at 2 kHZ PWM only, and only as a
stand-alone inverter module (“K” in position 13).
Position
1-3 4 5-7 8 9 101112 13 1415161718
20L E 800 A 0 E N N A N 1 0 W A
a bc defgh i jklmn
d
Enclosure
Code Type
Conformal
Coating
A NEMA/UL Type 1, IP20 ✝ No
N Open-Chassis Style/IP00 ❖ No
✝ Frame 3 complete drive.
❖ Frame 2 drive and Frame 3 input filter and power
modules.
e
HIM
Code Operator Interface
0 No HIM/Blank Cover
3 Full Numeric LCD ♠
5 Programmer Only LCD ♠
C Door-Mounted Full Numeric LCD ✝
♠ Frame 2 and Frame 3 power modules.
✝ Frame 3 complete drive only.
f
Documentation
Code Documents Ship Carton
E English Doc Set Yes
N No Documentation Yes
Q No Documentation No
g
Brake
Code w/Brake IGBT
NNo
h
Brake Resistor
Code w/Resistor
NNo
i
Equipment Type
Code Description Frame
A
Complete Regenerative
Drive - Std. Interrupt Rating
2, 3A, and 3B
C Input Filter 3A and 3B
E
Combined Active Converter/
Inverter Power Module
3A only
G
Active Converter
Power Module
3B only
J
Inverter Power Module -
Coupled Version
3B only
K
Inverter Power Module -
Common DC Bus Version
3B only
L Dual Inverter Power Module 3A only
P
Active Converter Power
Module - Stand Alone Version
3B only
X Spare Power Module ◆ 3A and 3B
◆ No control cassettes.
j
Comm Slot
Code Communication Option
DPI
User-Install
ed Kit Cat.
No. ✧
NNone N
C ControlNet (Coax) - DPI ‡ 20-COMM-C
D DeviceNet - DPI ‡ 20-COMM-D
E EtherNet/IP - DPI ‡ 20-COMM-E
R RIO - DPI ‡ 20-COMM-R
S RS-485 DF-1 - DPI ‡ 20-COMM-S
1
DriveLogix Comm Option,
ControlNet (Coax) ✽
—
2
DriveLogix Comm Option,
ControlNet Redundant (Coax) ✽
—
3
DriveLogix Comm Option,
ControlNet (Fiber) ✽
—
4
DriveLogix Comm Option,
ControlNet Redundant (Fiber) ✽
—
5
DriveLogix Comm Option,
DeviceNet (Open
Connection) ✽
—
6
DriveLogix Comm Option,
DeviceNet (Twisted Pair) ✽
—
✧ For 700S Phase II Control with DriveLogix5730,
comm. slot option selections are mutually
exclusive. For two communication adapters, (DPI
and DriveLogix), select the DriveLogix comm.
slot option and order the DPI user installed kit
catalog number separately.
‡ 700 Vector Control uses DPI comm. slot options
only.
✽ DriveLogix comm. slot options require 700S
Phase II Control with DriveLogix5730.
