P-6 Overview
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
k
Control Option
Code Control Cassette
Logic
Expansion
Synch
Link
1
700VC
24V I/O
Base N/A N/A
2
700VC
115V I/O
Base N/A N/A
A 700S Ph. II Expanded No No
B 700S Ph. II Expanded No Yes
C 700S Ph. II Expanded Yes No ▲
D 700S Ph. II Expanded Yes Yes ▲
W None ❖ N/A N/A N/A
❖ Frame 3 input filter, Active Converter Power
Modules, and spare power modules.
▲ Requires DriveLogix5730.
Position
1-3 4 5-7 8 9 101112 13 1415161718
20L E 800 A 0 E N N A N 1 0 W A
a bc defgh i jklmn
l
Feedback
Code
Control
Option
Type
0 All None
1 700VC Encoder 5V/12V
A 700S Ph. II Resolver ❤
B 700S Ph. II Hi-Res. Stegmann Encoder ❤
C 700S Ph. II Multi-Device Interface ❤ ✠
E 700S Ph. II 2nd Encoder ❤
S 700S Ph. II Safe-Off (w/2nd Encoder) ❤
❤ Requires expanded cassette.
✠ Multi-Device Interface allows the connection of
the Stegmann and Temposonics linear sensors.
The Temposonics sensor cannot
be used to
close motor control or speed loops.
m
Additional 700S Configuration
Code Logix Option
Embedded
Comm.
WNone —
E Phase II Control No
K
Phase II Control
with DriveLogix5730
No
L
Phase II Control
with DriveLogix5730
EtherNet/IP
n
Coolant Type
Code Coolant Frame
N None 3 Input Filter only
AWater All
