Page #117 background imageLoading...
Page #117 background image
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Appendix A
Supplemental Drive Information
Specifications
The following specifications, unless otherwise noted, pertain to drives
equipped with 700 Vector Control or 700S Phase II Control.
For information on… See page…
Specifications
A-1
Horsepower/Current Ratings A-5
Watts Loss A-6
Fuse and Circuit Breaker Ratings A-6
Category
Specification
Frame 2 Frames 3A and 3B
Agency
Certification
Listed to UL508C and CAN/CSA-C2.2 No. 14-05. UL Listing for Frame 2 is applicable up to 480V AC. UL Listing for
Frame 3A and 3B is applicable up to 600V AC.
Marked for all applicable European Directives
(1)
EMC Directive (89/336/EEC)
EN 61800-3 Adjustable Speed electrical power drive systems
Low Voltage Directive (73/23/EEC)
EN 50178 Electronic Equipment for use in Power Installations
Certified to AS/NZS, 1997 Group 1, Class A.
These drives are also designed to meet the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 3.1 - Safety standards for Construction and Guide for Selection, Installation and Operation of Adjustable Speed Drive
Systems.
IEC 146 - International Electrical Code.
CMAA Specification #70 (Crane Manufacturers of America Association)
(1)
Applied noise impulses may be counted in addition to the standard pulse train causing erroneously high [Pulse Freq] readings.
U
c
US
L
®
N223
Category
Specification
Frame 2 Frames 3A and 3B
Protection 400V 480V 400V 480V 600V 690V
AC Input Overvoltage Trip: 528V AC 528V AC 528V AC 528V AC 760V AC 760V AC
AC Input Undervoltage Trip: 340V AC 340V AC 340V AC 340V AC 340V AC 340V AC
Bus Overvoltage Trip: 815V DC 815V DC 815V DC 815V DC 1168V DC 1168V DC
Bus Undervoltage Shutoff/Fault: 300V DC 300V DC 300V DC 300V DC 300V DC 300V DC
Nominal Bus Voltage: 600V DC 700V DC 600V DC 700V DC 900V DC 1000V DC
Heat Sink Thermistor: Monitored by microprocessor overtemp trip
Drive Overcurrent Trip
Software Overcurrent Trip:
Hardware Overcurrent Trip:
200% of rated current (typical)
220-300% of rated current (dependent on drive rating)
Line Transients: Up to 6000 volts peak per IEEE C62.41-1991
Control Logic Noise Immunity: Showering arc transients up to 1500V peak
