A-2 Supplemental Drive Information
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Protection
(continued)
Logic Control Ride-Thru
Vector Control: 0.5 seconds minimum, 2 seconds typical
700S Phase II Control: 0.25 seconds, drive not running
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Environment Altitude: 1000 m (3280 ft.) at rated current. See Derating Guidelines
on page A-4 for operation above 1000
m (3280 ft.).
Maximum Surrounding Air
Temperature w/o Derating:
IP20, NEMA/UL Type 1: 0 to 50°C (32 to 122°F) 0 to 40°C (32 to 104°F)
Storage Temperature
(all constructions): –40 to 85°C (–40 to 185°F)
Atmosphere: Important: Drive must
not be installed in an area where the ambient atmosphere contains
volatile or corrosive gas, vapors or dust. If the drive is not going to be installed for a period of time,
it must be stored in an area where it will not be exposed to a corrosive atmosphere.
Relative Humidity: 5 to 95% non-condensing
Shock: 10G peak for 11 milliseconds duration (± 1.0 ms)
Vibration: 0.152 mm (0.006 in.) displacement, 1G peak, 5.5 Hz
Sound: Frame 2: Not available at time of publication. Frame 3A: 78 dB Frame 3B: 76 dB
Note: Sound pressure level is measured at 1 meter.
Electrical Voltage Tolerance
Vector Control: For full power and operating range, see the PowerFlex 700 Adjustable Frequency AC Drive—
Series B User Manual (publication 20B-UM002), Appendix C.
700S Phase II Control: For full power and operating range, see the PowerFlex 700S High Performance AC Drive—Phase
II Control User Manual (publication 20D-UM006), Appendix C.
Input Frequency Tolerance: 27-93 Hz.
Input Phases: Three-phase input provides full rating for all drives.
Displacement Power Factor: 0.98 across entire speed range.
Efficiency: 96.2% at rated amps, nominal line volts. 97.5% at rated amps, nominal line volts.
Maximum Short Circuit Current
Rating: To match specified circuit breaker capability, ≤
200,000 Amps
Actual Short Circuit Rating: Determined by AIC rating of installed circuit breaker.
Motor Lead Lengths: 76 meters (250 feet) total
Control Method: Sine coded PWM with programmable carrier frequency.
Carrier Frequency: 2, 4, or 8 kHz. Drive rating based on 4 kHz.
Derating Guidelines
on page A-4 for more
information.
2 or 4 kHz. Drive rating based on 4 kHz.
Output Voltage Range: 0 to rated motor voltage
Output Frequency Range
Vector Control: 0 to 420 Hz
700S Phase II Control: 0 to 350 Hz
Frequency Accuracy
(Vector Control only)
Digital Input:
Analog Input:
Within ± 0.01% of set output frequency.
Within ± 0.4% of maximum output frequency
Frequency Control
(Vector Control only):
Speed Regulation - w/Slip Compensation (Volts per Hertz Mode)
0.5% of base speed across 40:1 speed range
40:1 operating range
10 rad/sec bandwidth
Speed Regulation - w/Slip Compensation (Sensorless Vector Mode)
0.5% of base speed across 80:1 speed range
80:1 operating range
20 rad/sec bandwidth
Category
Specification
Frame 2 Frames 3A and 3B
