PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Chapter 5
Programming and Parameters
This chapter provides information about specific 700 Vector Control
parameters and specific 700S Phase II Control parameters that are affected
when used in a PowerFlex 700L Liquid-Cooled drive power structure.
Affected 700 Vector Control
Parameters
Utility File
For the following Utility file parameters, Bit 20 will be set when there is an
alarm present in the Active Converter.
For information on … See page…
Affected 700 Vector Control Parameters
5-1
Affected 700S Phase II Control Parameters 5-5
File Group
No. Parameter Name & Description Values
UTILITY
Diagnostic
211 [Drive Alarm 1]
Displays alarm conditions that presently exist in the drive.
“Prof SetHome” will be set if the alarm is configured in [Alarm Config 1], “Prof/Indexer” is
configured in [Speed/Torque Mod] and the homing routine has not been successfully
completed.
Read Only
Bit
Definition
Ground Warn Load Loss In PhaseLoss Motor Therm Waking Decel Inhibt Drv OL Lvl 2 Drv OL Lvl 1 IntDBRes OH Anlg in Loss Str At PwrUp Power Loss UnderVoltage Prechrg Actv
Default x00000000x000000
Bit 1514131211109876543210
1 = Condition True
0 = Condition False
x = Reserved
Bit
Definition
Active Cnvtr PTC HW Prof SetHome Adj Volt Ref
Default xxxxxxxxxxx0x000
Bit 31302928272625242322212019181716
1 = Condition True
0 = Condition False
x = Reserved
