Frame 2 Installation 2-17
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Installing Output Wiring from the Drive Output Terminals to the Motor
Important: See the PowerFlex 700L Technical Data, publication
20L-TD001, for motor lead length restrictions.
Use the following steps to connect the AC output power wiring from the
drive to the motor:
1. Route the three-phase AC output power motor leads to the drive power
module.
Do not route more than three sets of motor leads through a single
conduit. This will minimize cross-talk that could reduce the
effectiveness of noise reduction methods. If more than three drive/motor
connections per conduit are required, shielded cable must be used. If
possible, each conduit should contain only one set of motor leads.
2. Connect the three-phase AC power motor leads to the U/T1, V/T2, and
W/T3 output power terminals. For terminal locations, see Figure 2.15
.
Tighten the AC output power terminal connections to the proper torque
as shown in Table 2.B
.
!
ATTENTION: Do not route signal and control wiring with
power wiring in the same conduit. This can cause interference
with drive operation. Failure to observe these precautions could
result in damage to, or destruction of, the equipment
!
ATTENTION: Unused wires in conduit must be grounded at
both ends to avoid a possible shock hazard caused by induced
voltages. Also, if a drive sharing a conduit is being serviced or
installed, all drives using this conduit should be disabled to
eliminate the possible shock hazard from cross-coupled motor
leads. Failure to observe these precautions could result in bodily
injury.
