1-8 General Installation Information
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Essential Requirements for CE Compliance
Conditions 1-6 listed below must be satisfied for PowerFlex 700L
Liquid-Cooled AC drives to meet the requirements of EN61800-3:
1. Standard PowerFlex 700L Liquid-Cooled CE-compliant drive. For the
Frame 2 drive, kit Catalog Number SK-L1-CHK2-F2, which includes
common mode chokes and shielded cable clamps, must be installed
according to its included instructions (publication 20L-IN011). For
Frame 3A and 3B, the drive must be installed in a suitable enclosure
which attenuates radio frequency emissions (Rittal TS 8 or equivalent).
2. System grounding as described on page 1-2
.
3. Output power wiring to the motor, control (I/O) and signal wiring must
employ cable with a braided shield with coverage of 75% or greater, or
cables must be housed in metal conduit, or equivalent shielding must be
provided.
4. All control (I/O) and signal wiring to the drive must use cable with a
braided shield providing 75% or greater coverage, or the cables be
housed in a metal conduit, or equivalent shielding must be provided.
When shielded cable is used, only the drive end of the cable shield
should be terminated with a low-impedance connection to earth.
5. The shields of all shielded cables must be terminated with the proper
shielded connectors to chassis/earth.
6. Motor cables must not exceed 20 meters (65.6 feet) in length.
7. Motor cabling must be separated from control and signal wiring
wherever possible.
8. Review important precautions/attention statements throughout this
manual before installing the drive.
C-Tick Conformity
Compliance of PowerFlex 700L Liquid-Cooled AC drives with the
Australian Radiocommunications Act of 1992 has been demonstrated
through compliance with EN61800-3. Both the General Notes and the
Essential Requirements for CE Compliance provided above apply to C-Tick
compliance for PowerFlex 700L Liquid-Cooled AC drives.
C-Tick Declarations of Compliance are available online at: www.ab.com/
certification/c-tick/index.html
