3-6 Frame 3A and 3B Installation
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Figure 3.5 Frame 3A Dual Inverter Power Module Installation Dimensions
44 (1.75)
23 (0.90)
DETAIL A
Ø 14 ( Ø 0.56)
21 (0.81)
25 (1.00)
51 (2.00)
368 (14.50)
55 (2.16)
57 (2.24)
57 (2.24)
37 (1.46)
100 (3.95)
100 (3.95)
86 (3.39)
86 (3.39)
72 (2.83)
72 (2.83)
24 (0.94)
255 (10.05)
Top
Bot
119 (4.67)
119 (4.67)
119 (4.67)
119 (4.67)
119 (4.67)
396 (15.59)
1326 (52.20)
265 (10.44)
402 (15.82)
567 (22.32) 51 (1.99)
DC Pos.
DC
Neg.
See
DETAIL A
See
DETAIL B
97 (3.82)
44 (1.75)
21 (0.81)
38 (1.50)
19 (0.73)
38 (1.50)
DETAIL B DETAIL C
Ø 14 ( Ø 0.56)
Dimensions are in millimeters and (inches).
Ø 14 ( Ø 0.56)
44 (1.75)
44 (1.75)
16 (0.63)
76 (2.98)
16 (0.63)
BACK VIEW
LEFT SIDE VIEW FRONT VIEW
AIRFLOW
U/T1
V/T2
W/T3
U/T1
V/T2
W/T3
15 (0.60)
700 (27.58)
362 (14.25)
12 (0.45)
39 (1.56)
175 (6.89)
GRD
51 (1.99)
1200
(47.25)
39 (1.56)
175 (6.89)
See DETAIL C
Approximate Weight kg (lbs.)
Power Module Power Module and Packaging
113.9 (251) 145.6 (321)
