5-4 Programming and Parameters
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
COMMUNICATION
Masks & Owners
291 [Direction Owner]
Adapter that presently has exclusive control of direction changes.
See [Stop Owner]
292 [Reference Owner]
Adapter that has the exclusive control of the command frequency source selection.
See [Stop Owner]
293 [Accel Owner]
Adapter that has exclusive control selecting [Accel Time 1, 2].
See [Stop Owner]
294 [Decel Owner]
Adapter that has exclusive control selecting [Decel Time 1, 2].
See [Stop Owner]
295 [Fault Clr Owner]
Adapter that is presently clearing a fault.
See [Stop Owner]
296 [MOP Owner]
Adapters that are presently issuing increases or decreases in MOP command
frequency.
See [Stop Owner]
297 [Local Owner]
Adapter that has requested exclusive control of all drive logic functions. If an adapter
is in local lockout, all other functions (except stop) on all other adapters are locked out
and non-functional. Local control can only be obtained when the drive is not running.
See [Stop Owner]
Security
595 [Port Mask Act]
Bits 0-6 indicate status for DPI port communications. Bit 15 indicates when security
software is controlling the parameter.
Read Only
596 [Write Mask Cfg]
Enables/disables write access (parameters, links, etc.) for DPI ports. Changes to this
parameter only become effective when power is cycled, the drive is reset, or bit 15 of
[Write Mask Actv] transitions from “1” to “0.”
597 [Write Mask Act]
Status of write access for DPI ports. When bit 15 is set, network security is controlling
the write mask instead of [Write Mask Cfg].
Read Only
598 [Logic Mask Act]
Indicates status of the logic mask for DPI ports. When bit 15 is set, network security is
controlling the logic mask instead of [Logic Mask].
Read Only
File Group
No. Parameter Name & Description Values
Bit
Definition
Security DPI Port 6 DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1 Host
Default 0xxxxxxxx1111111
Bit 1514131211109876543210
1 = Active
0 = Not Active
x = Reserved
Bit
Definition
DPI Port 6 DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1
Default xxxxxxxxx111111x
Bit 1514131211109876543210
1 = Write Permitted
0 = Read Only
x = Reserved
Bit
Definition
Security DPI Port 6 DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1
Default 0xxxxxxxx111111x
Bit 1514131211109876543210
1 = Write Permitted
0 = Read Only
x = Reserved
Bit
Definition
Security DPI Port 6 DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1 Digital In
Default 0xxxxxxxx1111111
Bit 1514131211109876543210
1 = Control Permitted
0 = Control Masked
x = Reserved
