Loading Media
2
Basic Operation
40
2. Pass the media through the printer and secure the media holders.

Pass the media through the printer and secure the media holders.

Pull out the media over the platen.

Check both edges of the media are placed on the grit rollers.
Be sure to place the right edge of the media on the right end grit rollers.
Grit rollers
Grit rollers
Front
Grit rollers
Pinch rollers
