Reference Manual
00809-0100-4026, Rev FA
July 2009
A-3
Rosemount 5400 Series
Environment
Ambient Temperature
(5)
-40°F to 176°F (-40°C to 80°C).
LCD readable in: -4°F to 158°F (-20°C to 70°C).
Storage Temperature -58°F to 194°F (-50°C to 90°C). LCD: -40°F to 185°F (-40°C to 85°C)
Flange Temperature See “Temperature and Pressure Ratings” on page A-4.
Process Pressure See “Temperature and Pressure Ratings” on page A-4.
Humidity 0 - 100% Relative Humidity, non condensating
Factory Sealed Yes
Ingress Protection Type 4X, IP66, IP67
EU Directive compliance CE mark, 93/68/EEC
Radio Approvals
(6)(7)
FCC part 15C (1998)
(8)
, R&TTE (EU directive 1999/5/EC), and IC (RSS210-5)
Electromagnetic Compatibility
(9)
Emission and Immunity: EMC directive 89/336/EEC. EN61326-1:1997 incl. A1:1998 and
A2:2001. NAMUR recommendations NE21.
Transient / Built-in Lightning Protection
(9)
EN61326, IEC 801-5, level 1 kV.
T1 option: Additionally, the transmitter complies with ANSI / IEEE 62.41 transient
protection and ANSI/IEEE C37.90.1 surge protection. The protection includes gas-filled
discharge tubes and semiconductor components.
Pressure Equipment Directive (PED) 97/23/EC
Vibration Resistance
(9)
IEC 60770-1 level 1
(1) Ideal metal plate with no disturbing objects.
Temperature: + 68 °F (20 °C).
Pressure: 14-15 psi (960-1060 mbar).
Humidity: 25-75 % RH.
(2) If the reference conditions are not met, an offset adjustment for the zero reference point may be necessary. The offset may be up to
± 10 mm.
(3) Transition Zones are areas where measurements are not recommended.
(4) PFA is a fluoropolymer with properties similar to PTFE.
(5) Temperature may be limited by the selected product certificate, see “Product Certifications” on page B-1.
(6) Only a limited selection is presented. Contact your local Emerson Process Management representative for more information.
(7) For Japan: “Install device on tanks or pipes made of metal”.
(8) For 5402: “This device is authorized for use in tank-mounted applications, including metal tanks as well as concrete, plastic, glass and other non-conductive
tanks.” No specific restrictions are stated for the 5401.
(9) The device may also comply with other standards. Consult your local Emerson Process Management representative.
