Rosemount 5402 - Advanced Analog Output Configuration

Reference Manual
00809-0100-4026, Rev FA
July 2009
C-3
Rosemount 5400 Series
ADVANCED ANALOG
OUTPUT SETTINGS
The 20 mA Upper Range Value should be outside the Hold Off Distance (see
“Hold Off Distance” on page C-2) in order to utilize the full range of the analog
output.
Figure C-2. Advanced Range
Value settings
20 mA Upper Range Value (URV)
Product Level
4 mA Lower Range Value (LRV)
Range 0-100 %
Upper Reference Point
Min LevelOffset (C)
Hold Off Distance
Lower Reference Point
(Level=0)
