Rosemount 5400 Series
LCD Parameters
Table 6-1. LCD parameters and
presentation on display.
Parameter Presentation on display Description
Level LVL Product level.
Distance DST Distance from the upper reference point to the product surface.
Level Rate LR The speed of level movement up or down.
Signal Strength AMP The signal amplitude of the surface echo.
Volume Only measurement unit is shown. Total product volume.
Internal Temperature ITEMP Temperature inside the transmitter housing.
AOut Current ANOUT Analog Output 4 -20 mA current.
Percent of Range % RNG Level value in percent of total measurement range.
Comm Quality COM Q
