Reference Manual
00809-0100-4026, Rev FA
July 2009
Rosemount 5400 Series
www.rosemount.com
Section 4 Electrical Installation
Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-1
Cable/Conduit Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-3
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-5
Cable Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-5
Hazardous Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-5
External Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-5
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-5
Connecting the Transmitter . . . . . . . . . . . . . . . . . . . . . . . .page 4-6
Non-Intrinsically Safe Power Supply . . . . . . . . . . . . . . . . page 4-7
Intrinsically Safe Power Supply . . . . . . . . . . . . . . . . . . . . page 4-8
Optional Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-9
SAFETY MESSAGES Procedures and instructions in this section may require special precautions to
ensure the safety of the personnel performing the operations. Information that
raises potential safety issues is indicated by a warning symbol ( ). Please
refer to the following safety messages before performing an operation
preceded by this symbol.
