Reference Manual

00809-0100-4026, Rev FA

July 2009

B-9

Rosemount 5400 Series

Technology Institution of

Industrial Safety (TIIS)

Approval

Figure B-7. Approval Label

Technology Institution of

Industrial Safety (TIIS)

E4 Flameproof:

Transmitter: Ex d [ia] IIC T4

Antenna: Ex ia IIC T4

Installation Drawing: 05400-00375A.
