Rosemount 5402 - Spare Parts List for Transmitter

Reference Manual
00809-0100-4026, Rev FA
July 2009
Rosemount 5400 Series
A-18
SPARE PARTS
Spare parts list Transmitter head Model 5402
Model Product Description
5402 High frequency version (~26 GHz)
Code Housing Material
A Polyurethane-covered Aluminum
S Stainless Steel, Grade CF8M (ASTM A743)
Code Signal Output
H 4-20 mA with HART
®
communication
Code Conduit / Cable Threads
1 1/2 inch - 14 NPT
2 M20 x 1.5 adapter
E M12, 4-pin, Male Connector (eurofast
®
)
(1)
(1) Options E (eurofast
®
) and M (minifast
®
) are not available with Explosion-proof or Flameproof approvals.
M A size Mini, 4-pin, Male Connector (minifast
®
)
(1)
Code Product Certifications
NA No Product Certificates
E1 ATEX Flameproof
(1)
I1 ATEX Intrinsic Safety
E3 NEPSI Flameproof
(1)
I3 NEPSI Intrinsic Safety
IC NEPSI FISCO Intrinsic Safety
E4 TIIS Flameproof
(2)
(2) G ½ in. SST cable gland is included in delivery.
E5 FM Explosion-proof
(1)
I5 FM Intrinsic Safety and Non-incendive
E6 CSA Explosion-proof
(1)
I6 CSA Intrinsic Safety
E7 IECEx Flameproof
(1)
I7 IECEx Intrinsic Safety
Code Antenna Type
NA No antenna, only transmitter head
Code Tank Sealing
NA No antenna, only transmitter head
Code Process Connection
NA No antenna, only transmitter head
Code Options
M1 Integral digital display
T1 Transient Protection Terminal Block (standard with FISCO options)
Software Configuration
C1 Factory configuration (CDS required with order)
Alarm Limit Configuration
C4 NAMUR alarm and saturation levels, high alarm
C8 Low alarm
(3)
(standard Rosemount alarm and saturation levels)
(3) The standard alarm setting is high.
Special Certificates
Q4 Calibration Data Certificate
