Reference Manual
00809-0100-4026, Rev FA
July 2009
A-17
Rosemount 5400 Series
Code Options
M1 Integral digital display
GC Transparent meter glass protection cover made of PTFE / FEP
T1 Transient Protection Terminal Block (standard with FISCO options)
Software Configuration
C1 Factory configuration (CDS required with order)
Alarm Limit Configuration
C4 NAMUR alarm and saturation levels, high alarm
C8 Low alarm
(6)
(standard Rosemount alarm and saturation levels)
Special Certificates
N2 Certificate of compliance with guidelines in NACE MR0175/ISO 15156 and NACE MR0103
(7)
Q4 Calibration Data Certificate
Q8 Material Traceability Certification per EN 10204 3.1
(8)
QG Calibration Certificate and GOST Verification Certificate
Special Procedures
P1 Hydrostatic testing
(5)
Antenna Modification
S3 Extended Cone Antenna in 316 / 316L / EN 1.4404 SST. Maximum recommended nozzle height is 20 in. (500 mm).
(9)
Typical Model Number: 5401 A H 1 NA 4S PV CA - M1 C1
(1) Options E (eurofast
®
) and M (minifast
®
) are not available with Explosion-proof or Flameproof approvals.
(2) G ½ in. SST cable gland is included in delivery.
(3) PFA is a fluoropolymer with properties similar to PTFE.
(4) All-PFA Rod antennas (1R or 2R) require all-PFA tank seal (PD).
(5) Certain process connections are not available with hydrostatic testing (P1).
(6) The standard alarm setting is high.
(7) Requires wetted flange plate cone antennas (3H-8H, 3M-8M, 3N-8N) or rod antennas (1R-4R).
(8) Certificate includes all pressure retaining wetted parts.
(9) Requires a SST cone antenna (4S-8S).
