Rosemount 5402 - Page 136

Reference Manual
00809-0100-4026, Rev FA
July 2009
Rosemount 5400 Series
A-16
Code Antenna - Size and Material
Rod Antennas
1R Short version, all-PFA
(3)(4)
, with wetted flange plate, max. nozzle height 4 in. (100 mm), free propagation only
2R Long version, all-PFA
(3)(4)
, with wetted flange plate, max. nozzle height 10 in. (250 mm), free propagation only
3R Short version, SST+PFA
(3)
, max. nozzle height 4 in. (100 mm), free propagation only
4R Long version, SST+PFA
(3)
, max. nozzle height 10 in. (250 mm), free propagation only
Other Antennas
XX
Customer specific
Code Tank Sealing
PV PTFE with Viton
®
fluoroelastomer o-rings
PK PTFE with Kalrez
®
6375 perfluoroelastomer o-rings
PE PTFE with EPDM o-rings
PB PTFE with Buna-N o-rings
PD All-PFA
(3)
rod antennas (O-rings are not wetted)
Code Process Connection and Material
ANSI Flanges (316 / 316L SST)
AA 2 in. 150 lbs
AB 2 in. 300 lbs
BA 3 in. 150lbs
BB 3 in. 300 lbs
CA 4 in. 150 lbs
CB 4 in. 300 lbs
DA 6 in. 150 lbs
EA 8 in. 150 lbs
EN (DIN) Flanges (EN 1.4404 SST)
HB DN 50 PN 40
IB DN 80 PN 40
JA DN 100 PN 16
JB DN 100 PN 40
KA DN 150 PN 16
LA DN 200 PN 16
JIS Flanges (EN 1.4404 SST)
UA 50A 10K
VA 80A 10K
XA 100A 10K
YA 150A 10K
ZA 200A 10K
Tri-Clamp Fittings
AT 2 in. Tri-Clamp
BT 3 in. Tri-Clamp
CT 4 in. Tri-Clamp
Threaded (316L / EN 1.4404 SST)
RA 1.5-in. NPT
(5)
Other
BR Bracket Mounting, 316L / EN 1.4404 SST
(5)
XX Customer specific
