Rosemount 5402 - Page 135

Reference Manual
00809-0100-4026, Rev FA
July 2009
A-15
Rosemount 5400 Series
Model Code for Rosemount 5401 Radar Level Transmitter
Model Product Description
5401 Low frequency version (~6 GHz)
Code Housing Material
A Polyurethane-covered Aluminum
S Stainless Steel, Grade CF8M (ASTM A743)
Code Signal Output
H 4-20 mA with HART
®
communication
Code Conduit / Cable Threads
1 1/2 inch - 14 NPT
2 M20 x 1.5 adapter
E M12, 4-pin, Male Connector (eurofast
®
)
(1)
M A size Mini, 4-pin, Male Connector (minifast
®
)
(1)
Code Product Certifications
NA No Product Certificates
E1 ATEX Flameproof
(1)
I1 ATEX Intrinsic Safety
E3 NEPSI Flameproof
(1)
I3 NEPSI Intrinsic Safety
IC NEPSI FISCO Intrinsic Safety
E4 TIIS Flameproof
(2)
E5 FM Explosion-proof
(1)
I5 FM Intrinsic Safety and Non-incendive
E6 CSA Explosion-proof
(1)
I6 CSA Intrinsic Safety
E7 IECEx Flameproof
(1)
I7 IECEx Intrinsic Safety
Code Antenna - Size and Material
Cone Antennas
3S 3 in. DN 80, 316L SST (EN 1.4404), pipe installations only
4S 4 in. DN 100, 316L SST (EN 1.4404)
6S 6 in. DN 150, 316L SST (EN 1.4404)
8S 8 in. DN 200, 316L SST (EN 1.4404)
3H 3 in. DN 80, Alloy C-276 (UNS N10276) with wetted flange plate, pipe installations only
4H 4 in. DN 100, Alloy C-276 (UNS N10276) with wetted flange plate
6H 6 in. DN 150, Alloy C-276 (UNS N10276) with wetted flange plate
8H 8 in. DN 200, Alloy C-276 (UNS N10276) with wetted flange plate
3M 3 in. DN 80, Alloy 400 (UNS N04400) with wetted flange plate, pipe installations only
4M 4 in. DN 100, Alloy 400 (UNS N04400) with wetted flange plate
6M 6 in. DN 150, Alloy 400 (UNS N04400) with wetted flange plate
8M 8 in. DN 200, Alloy 400 (UNS N04400) with wetted flange plate
3N
3 in. DN 80, 316L SST (EN 1.4404), with wetted flange plate, pipe installations only. Complies with guidelines in NACE
MR0175/ISO 15156 and NACE MR0103.
4N
4 in. DN 100, 316L SST (EN 1.4404), with wetted flange plate. Complies with guidelines in NACE MR0175/ISO 15156
and NACE MR0103.
6N
6 in. DN 150, 316L SST (EN 1.4404), with wetted flange plate. Complies with guidelines in NACE MR0175/ISO 15156
and NACE MR0103.
8N
8 in. DN 200, 316L SST (EN 1.4404), with wetted flange plate. Complies with guidelines in NACE MR0175/ISO 15156
and NACE MR0103.
Continued on the Next Page
