Reference Manual
00809-0100-4026, Rev FA
July 2009
Rosemount 5400 Series
A-12
ORDERING INFORMATION
Model Code for Rosemount 5402 Radar Level Transmitter
Model Product Description
5402 High frequency version (~26 GHz)
Code Housing Material
A Polyurethane-covered Aluminum
S Stainless Steel, Grade CF8M (ASTM A743)
Code Signal Output
H 4-20 mA with HART
®
communication
Code Conduit / Cable Threads
1 1/2 inch - 14 NPT
2 M20 x 1.5 adapter
E M12, 4-pin, Male Connector (eurofast
®
)
(1)
M A size Mini, 4-pin, Male Connector (minifast
®
)
(1)
Code Product Certifications
NA No Product Certificates
E1 ATEX Flameproof
(1)
I1 ATEX Intrinsic Safety
E3 NEPSI Flameproof
(1)
I3 NEPSI Intrinsic Safety
IC NEPSI FISCO Intrinsic Safety
E5 FM Explosion-proof
(1)
I5 FM Intrinsic Safety and Non-incendive
E6 CSA Explosion-proof
(1)
I6 CSA Intrinsic Safety
E7 IECEx Flameproof
(1)
I7 IECEx Intrinsic Safety
Code Antenna - Size and Material
Cone Antennas
2S 2 in. DN 50, 316L SST (EN 1.4404)
3S 3 in. DN 80, 316L SST (EN 1.4404)
4S 4 in. DN 100, 316L SST (EN 1.4404)
2H 2 in. DN 50, Alloy C-276 (UNS N10276) with wetted flange plate
3H 3 in. DN 80, Alloy C-276 (UNS N10276) with wetted flange plate
4H 4 in. DN 100, Alloy C-276 (UNS N10276) with wetted flange plate
2M 2 in. DN 50, Alloy 400 (UNS N04400) with wetted flange plate
3M 3 in. DN 80, Alloy 400 (UNS N04400) with wetted flange plate
4M 4 in. DN 100, Alloy 400 (UNS N04400) with wetted flange plate
2N
2 in. DN 50, 316L SST (EN 1.4404), with wetted flange plate. Complies with guidelines in NACE MR0175/ISO 15156 and
NACE MR0103.
3N
3 in. DN 80, 316L SST (EN 1.4404), with wetted flange plate. Complies with guidelines in NACE MR0175/ISO 15156 and
NACE MR0103.
4N
4 in. DN 100, 316L SST (EN 1.4404), with wetted flange plate. Complies with guidelines in NACE MR0175/ISO 15156
and NACE MR0103.
Process Seal Antennas
2P 2 in. DN 50, PTFE
3P 3 in. DN 80, PTFE
4P 4 in. DN 100, PTFE
