Rosemount 5402 - Page 133

Reference Manual
00809-0100-4026, Rev FA
July 2009
A-13
Rosemount 5400 Series
Other Antennas
XX Customer specific
Code Tank Sealing
PV PTFE with Viton
®
fluoroelastomer o-rings
PK PTFE with Kalrez
®
6375 perfluoroelastomer o-rings
PE PTFE with EPDM o-rings
PB PTFE with Buna-N o-rings
Code Process Connection and Material
ANSI Flanges (316 / 316L SST)
AA 2 inch, 150 lbs
AB 2 inch, 300 lbs
BA 3 inch, 150 lbs
BB 3 inch, 300 lbs
CA 4 inch, 150 lbs
CB 4 inch, 300 lbs
DA 6 inch, 150 lbs
EA 8 inch, 150 lbs
EN (DIN) Flanges (EN 1.4404 SST)
HB DN 50 PN 40
IB DN 80 PN 40
JA DN 100 PN 16
JB DN 100 PN 40
KA DN 150 PN 16
LA DN 200 PN 16
JIS Flanges (EN 1.4404 SST)
UA 50A 10K
VA 80A 10K
XA 100A 10K
YA 150A 10K
ZA 200A 10K
Other Flanges
BR Bracket Mounting, 316L / EN 1.4404 SST
(2)
XX Customer specific
Code Options
M1 Integral digital display
GC Transparent meter glass protection cover made of PTFE / FEP
T1 Transient Protection Terminal Block (standard with FISCO options)
Software Configuration
C1 Factory configuration (CDS required with order)
Alarm Limit Configuration
C4 NAMUR alarm and saturation levels, high alarm
C8 Low alarm
(3)
(standard Rosemount alarm and saturation levels)
Special Certificates
N2 Certificate of compliance with guidelines in NACE MR0175/ISO 15156 and NACE MR0103
(4)
Q4 Calibration Data Certificate
Q8 Material Traceability Certification per EN 10204 3.1
(5)
QG Calibration Certificate and GOST Verification Certificate
