Rosemount 5402 - Conduit Electrical Connector Wiring (Using Minifast)

Reference Manual
00809-0100-4026, Rev FA
July 2009
Rosemount 5400 Series
4-4
Conduit Electrical
Connector Wiring (using
Minifast
®
)
Figure 4-2. Quick Connect
Housing Pin-Out.
For wiring details, refer to pin-out drawing and the cordset manufacturer’s
installation instructions.
For 5400 transmitters with conduit electrical connector M, refer to the cordset
manufacturer’s installation instructions for wiring details.
“+”
“-”
No Connection
Ground
