Rosemount 5400 Series
Code Process Connection
ANSI Flanges (316 / 316L SST)
AA 2 inch, 150 lbs
AB 2 inch, 300 lbs
BA 3 inch, 150 lbs
BB 3 inch, 300 lbs
CA 4 inch, 150 lbs
CB 4 inch, 300 lbs
DA 6 inch, 150 lbs
EA 8 inch, 150 lbs
EN (DIN) Flanges (EN 1.4404 SST)
HB DN 50 PN 40
IB DN 80 PN 40
JA DN 100 PN 16
JB DN 100 PN 40
KA DN 150 PN 16
LA DN 200 PN 16
JIS Flanges (EN 1.4404 SST)
UA 50A 10K
VA 80A 10K
XA 100A 10K
YA 150A 10K
ZA 200A 10K
Tri-Clamp Fittings
AT 2 in. Tri-Clamp
BT 3 in. Tri-Clamp
CT 4 in. Tri-Clamp
Other Flanges
RA 1.5-in. NPT
BR Bracket Mounting, 316L / EN 1.4404 SST
Code Options
Special Certificates
Q8 Material Traceability Certification per EN 10204 3.1
(1)
N2 Certificate of compliance with guidelines in NACE MR0175/ISO 15156 and NACE MR0103
(2)
Special Procedures
P1 Hydrostatic testing
(1) Certificate includes all pressure retaining wetted parts.
(2) Requires wetted flange plate cone antennas (3H-8H, 3M-8M, 3N-8N) or rod antennas (1R-4R).
