IIT-2000/2010/5000/5010 Instruction Manual/English
16 05/08/2015 Version No. 001
Display
240 X 64 dot matrix display (LCD)
Function keys
The function keys correspond to the soft-keys directly above on
the main display.
Pass/Fail
indicators
PASS
FAIL
The PASS and FAIL indicators light up upon a
PASS or FAIL test result at the end of a manual
test or automatic test.
ESC key
ESC
The ESC key is used to exit out of a menu or
cancel a setting.
PAGE key
PAGE
The PAGE key is used to view automatic test
information and test results.
Directional
arrow keys
The directional arrow keys are used to navigate
menus and parameter settings.
READY
indicator
READY
The READY indicator is lit when the tester is
ready to begin testing. The STOP button is used
to put the tester into READY status.
TEST indicator
TEST
The TEST indicator is lit when a test is on. The
START button is used to put the tester into TEST
status.
