IIT-2000/2010/5000/5010 Instruction Manual/English
50 05/08/2015 Version No. 001
2. Use the scroll wheel to set the HI SET/LO SET
limit*.
ACW (HI)
DCW (HI)
IR (LO)
GB (HI)
0.001mA~042.0mA (IIT-2000/2010)
0.001mA~110.0mA (IIT-5000/5010)
0.001mA~011.0mA (IIT-2000/2010)
0.001mA~021.0mA (IIT-5000/5010)
0001MΩ ~ 9999MΩ (IIT-2010)
0.001GΩ ~ 50.00GΩ (IIT-5010)
000.1mΩ ~ 650.0mΩ
3. Press the HI/LO soft-key again or press the
DOWN arrow key to switch between HI SET and
LO SET.
I / LH O
OR
I R G B A CW D CW I / LH O I M ET R
E
F R E Q = 0 H z 6
0 100
k V
IDE
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0MM A UN N A_
1 . 0 0 m A0L ES = 0T
0 0 . 1 S0A M P =R
T
2M A N U = * * * - 0 0
cursor
1 . 0 0 m AIH ES = 0T
m A
4. Use the scroll wheel to set the HI SET/LO SET
limit*.
